My Bike Fit and Wind Tunnel Testing

I spent the morning in the A2 Wind Tunnel in Mooresville, North Carolina doing one-minute intervals into a 30-mph headwind to get my new Blue Triad SL dialed in for this next season’s racing. While I had taken clients to wind tunnels before, this my first opportunity to get my own time trial bike and position tested.

I’ve had many bike fits done and highly recommend that as a necessity regardless of whether or not your next step will be a wind tunnel. A bike fit will cost you from $100 to $300 depending on how much time it takes and the reputation of the fitter. I found the A2 tunnel to be rather inexpensive as wind tunnels go. I’m used to having my clients pay up to $800 per hour. A2 charges _only_ $390 for an hour. I spent the better part of two hours on the saddle in the tunnel. And that’s about how much time my clients have also needed. That’s still a fair chunk of change so you want to come away with positive results. “Buying” a minute for a 40k is very expensive.

Again, I recommend that everyone has a bike fit done by a professional fitter. I go to a lot of races and see horrible bike positions that reduce power and increase drag – the worst possible combination. With a few small adjustments I could do wonders for nearly all of these riders (the others need bikes that fit – you can’t do much to correct that). It would take hours of weekly training for several months to build more power in order to reap the same benefit as a few basic adjustments of the bike set up would take.

So here’s what led me to Mooresville… After the new Blue TT bike was built up I met with Chris Pulleyn at Bicycle Ranch in Scottsdale, Arizona for a fit. Chris has done this for every athlete I’ve coached for the past three years. He is meticulous and determined to get an excellent position. Accompanying is a picture of Chris setting the position right at the end of the fit. I liked the position we came up with and felt both powerful and aerodynamic.

But there is a big difference between pedaling easily in a fit studio and racing on the road. The wind tunnel showed me that. On the first of 15 runs (a “run” lasts about 90 seconds and includes about 30 seconds of both the rider and the fans coming up to speed followed by about a minute at functional threshold power while readings are captured) I felt a little high. Fourteen runs later we had the bike set for a position that fit my needs – which is mostly 20km time trials. Had I been training for a longer event, especially something like an Ironman triathlon, the position would have been altogether different. The biggest change is that we would have shifted the focus from aggressively aerodynamic toward being far more comfortable.



The before-after pictures you see here show fairly well the changes that Mike Giraud at A2 made in my position. He started by lowering the handlebars. This was done four times for a total drop of 4.5cm. Each time I became a bit more aero, but power dropped off a bit also. By the fourth time the trade off wasn’t good and so he brought the bars back up 5mm. Then he began bringing the elbows in, about 3cm at a time for three tries. The last was too much and so I ended up with the elbow pads 3cm narrower than when we started. This made for a bit too much discomfort in trying t hold on to the S-bend aerobars and so he rotate them I so that the bar ends nearly touched.

After a try at making my shoulders narrower by lifting them toward my ears, which didn’t achieve very much, he tried a different helmet. My Garneau Rocket Air helmet (blue in pictures) was replaced by a Giro Advantage 2 (black in pictures). The Giro helmet fit a bit closer to my back and also seemed better shaped for my head. I also liked the heavily padded ear covers, which quieted the 30mph wind. (Interestingly, this latter is suggested by John Cobb to reduce the sound of the air thus reducing one’s perceived exertion. Only he achieves it by using ear plugs.)

The bottom line is that I wound up with my bars 4cm lower, my elbows 3cm narrower, my hands brought together by rotating the bar extensions, and different helmet. The power and drag numbers are not available as I write this. I will post them at another time.

I’m now ready to race – except for the fitness part.

Read Any Good Books?

I recently read a couple of books you may find enjoyable and informative:

Racing Weight by Matt Fitzgerald. Matt is a coaching colleague who I have always found to be level-headed with his training advice and have a firm foundation in research. Both qualities stand out in this book which hit the shelves in the last few months from Velo Press who also publishes many of my books. I never thought it possible to write an entire book on this topic. Writing a blog post on weight management for serious athletes seemed long when I did it some time ago. I was expecting a lot of meaningless fill with a book on the topic, but it is anything but that. I found every page to be sprinkled with ideas on how to manage your weight for better performance. And the book is extremely well researched. He often presents both sides of an issue and then explains why he sides with one of them. I find that an enlightening way to deal with topics so burdened with old wives' tales and misinformation. Matt has done a great job. I'd highly recommend reading it even if you don't need to lose any excess poundage. You'll come away with a better understanding of your physiology and also of food.

Trizophrenia by Jef Mallett. I don't usually read books like this but I have followed Jef's comic strips in our local paper (The Arizona Republic) and in VeloNews. In his comics he seems to frequently express something I've done or thought of myself while training. His book is no different. As a triathlete he has a good sense of what others in the sport are thinking. If you're a triathlete I'm sure you will enjoy the book. It's a quick read and will leave you contemplating what you do so seriously many hours a day while chuckling at the same time.

And a little bit of self-promotion... I'm currently working on a book which won't be out until next fall at the earliest (one chapter done!). I've received many questions from athletes over the years basically asking how to apply the principles described in my Training Bible books. This book does that. Based on a periodization model, you simply read the chapter related to the period you are just starting in your training and it will take you through all of the details including not only the period-specific workouts, but also testing, nutrition, mental challenges and common problems. And it will offer sample training plans for your race preparation. I think it's going to be a great book for helping you coach yourself more effectively.

Even More on Running Shoes

I always enjoy reading the sportsscientists.com blog written by Ross Tucker, PhD of Cape Town University and Jonathan Dugas, PhD of the University of Illinois in Chicago. They have a level-headed approach to training that I admire and they seem to be open to new ideas. Many in sport science (as in any science, I suppose) are deathly afraid of change because it means rethinking the area of suggested change and its overlapping areas. Acceptance of new ways also suggests that nothing is above re-examining and possibly changing. Change is scary.

But being open-minded to the possibility of change does not mean that every new idea that comes down the pike should be accepted at face value. That would lead to chaos in science as in any area of endeavor. New ways of seeing the world of training for endurance sport should be viewed with some degree of skepticism while taking a hard look at the concept from both a scientific and a real-world perspective. Tucker and Dugas seem to balance this very nicely.

I bring this up because they have just posted to their blog a piece on minimalist running shoes, barefoot running and normally shod running. It examines the science behind the website I mentioned a couple of days ago on this topic. If you're considering running in a less supportive shoe or even no shoe at all be sure to read the Tucker-Dugas post before making the switch.

More on Running Shoes

Here's an interesting view on running shoes and footsrike from a professor at Harvard University and colleagues (thanks for the heads up, Chad). The lead author, Daniel E. Lieberman, PhD, studies human bipedal movement from a paleolithic perspective. You may well find this interesting based on the comments that followed my previous posts on running shoes here and here. It seems there are some pretty strong opinions and even feelings on this topic among runners.

I should point out that the research leading to the website cited above was funded, in part, by Vibram FiveFingers, the makers of a minimalist foot cover (I hesitate to call it a 'shoe') for runners. While I always feel a bit of skepticism when I see that a study was funded by a business that may well benefit financially from the results, it doesn't necessarily mean that the conclusions are biased. You can read it yourself and draw your own conclusions.

More on Running Faster

As mentioned in a previous post on running faster, I have the triathletes I coach do some form of the basic strides drill year round. As with swimming, it seems you can never devote too much time to improving your run technique. I once coached a pro triathlete who was an All-American runner in college and considered one of the fastest runners in triathlon. I still had him work on technique year round. You should too.

The downhill strides workout described in the original running faster post is very simple. All you do is run fast for 20 seconds several times on a soft surface such as a grassy park that has a very slight decline (such as 1%). If you do not have a history of calf, Achilles or plantar fascia injuries then I'd have you substitute “uphill strides” for the downhill strides workout after a few weeks.

This session will help you develop more running force. As explained earlier, there are only two things you can do to run faster - increase your stride length or increase your cadence. What you would really like to do is both. In that previous post I described how to improve your cadence. Let's now look at how to improve stride length which is just another way of saying improve force.

Developing greater running force will make your stride longer without even trying. Combine that with the higher cadence you have been working on with downhill strides and your running is sure to improve. But it won’t happen overnight. Your aerobic system must also improve to allow you to maintain the combined higher cadence and longer stride. And the nervous system must also adapt to the changes. All of this will take some time as the aerobic and nervous systems change slowly. By the start of the Build period in a few weeks, if you’ve been diligent about both speed skills and force training, you will be running faster at the same effort as when you started Base training. You must be patient and persistent to realize the improvement. In the mean time, don't try to artificially increase your stride length while running. Let it happen naturally.

Uphill strides workouts for force are done on either a short, very steep hill or on something like the stairs you find in a football stadium or basketball arena. If you have had some Achilles, calf or plantar fascia injuries then you are better off using the stairs - if you do this workout at all. The ankle flexion is significant when running up a steep hill and puts a tremendous load on those soft tissues. For this reason I prefer stairs for this workout for most runners but they are harder to find than hills.

The uphill strides workout is simple. Warm-up well and then do three sets of three intervals up the hill or stairs. Run as hard as you can on each interval – but not so hard that your technique breaks down. If running stairs you may need to take two or even three steps with each stride depending on the width and rise of the stairs. Count 12, right-foot strikes stopping on the twelfth. Turn around and walk back down the hill or stairs. Do not run down. Jog easily for five minutes after each set.

This is a very risky workout. Be cautious with its progression. Do this no more than twice a week with at least 96 hours between them. Once a week is better for most athletes. Start with one set and add another each week for three weeks. If you have “glass legs” you would be wise not to do it at all. In that case just continue doing the downhill strides for speed skill. Not all of the athletes I coach do the uphill strides workout. I’m very conservative when it comes to risky running workouts. You must avoid injury.

Indoor Intervals

Someone asked me today what intervals could be done on an indoor trainer or treadmill to alleviate some of the boredom. Of course, what you do in training is more closely tied to your periodization, i.e., time until your first A-priority race of the season, than to your level of boredom. For example, some athletes, I know, are doing the Valley of the Sun bike stage race next month in Phoenix. If that’s an A race for you then higher intensity efforts are appropriate. But if your A race isn’t for a few months then lower intensity efforts are appropriate. Assuming you know what you should be working on in training right now, here are some workouts that may be done indoors – or outdoors for that matter, also. (If unsure of what you should be doing consult my Training Bible books – Chapter 6.)

Before each of the sessions described below warm-up by gradually increasing the intensity. The more intense the intervals, the longer the warm-up. Cool down after each interval session.

The intensity of these intervals is based on the following. Pick the one that suits you best…

• Rating of Perceived Exertion (RPE) on a 1 (low) to 10 (high) scale
• Heart Rate (HR) using the system found in my Training Bible books and Total Heart Rate Training book.
• Power zones are from Coggan’s system (Training and Racing With a Power Meter)
• Pace zones for running are found in my Triathlete’s Training Bible book

Note that the number of intervals and the duration of the intervals is not carved in stone. These may be changed either way to accommodate an athlete who is highly experienced or a novice. They are a starting point for someone who is moderately fit for this time of year.

WORKOUTS
Aerobic endurance intervals
Purpose: Improve cardiovascular system
RPE: 4-5
HR Zone: 2
Power Zone: 2
Pace Zone: 2
Workout: 3 x 20 minutes with 5 minute easy recoveries
Comments: Keep cadence comfortably high

Tempo intervals
Purpose: Improve muscular endurance
RPE: 6
HR Zone: 3
Power Zone: 3
Pace Zone: 3
Workout: 3 x 10 minutes with 3 minute easy recoveries
Comments: Cadence slightly lower than normal or 2% uphill on a treadmill

Threshold intervals
Purpose: Improve ability to process and remove acid build up and lift lactate threshold as a percentage of aerobic capacity
RPE: 7
HR Zone: 4-5a
Power Zone: 4
Pace Zone: 4-5a
Workout: 3 x 6 minutes with 2 minute easy recoveries
Comments: Cadence at comfortable level. May be done on a ‘hill.’

Anaerobic endurance intervals
Purpose: Improve aerobic capacity
RPE: 8-9
HR Zone: 5b
Power Zone: 5-6
Pace Zone: 5b
Workout: 5 x3 minutes with 3 minute easy recoveries
Comments: Keep cadence comfortably high, focus on technique

Speed skills intervals
Purpose: Improve economy
RPE: 8-9
HR Zone: not applicable
Power Zone: not applicable
Pace Zone: not applicable
Workout: 6-8 x 20 seconds with 90 seconds of easy spin/walk recoveries between intervals
Comments: Focus is entirely on one single aspect of technique such as run foot strike or pedaling through 12 o’clock position. Movement is fast at high cadence.

Anaerobic capacity intervals
Purpose: Improve power
RPE: 10
HR Zone: not applicable
Power Zone: 7
Pace Zone: 5c
Workout: 3 sets of 3 x 12 revolutions (count right foot 12 times) with 3 minute easy recoveries between intervals and 6 minutes between sets
Comments: These are essentially sprints. Form must be perfect or injury is possible.

Running Shoes, Part 2

I've got a layover in Denver on the way to Salt Lake City today so have a bit of time to expand on my comments below on running shoes. There have been a couple of comments posted by readers and I received a few emails on the subject also. So far these have overwhelmingly favored minimalism in running shoes selection with a few preferring barefoot and a couple the Vibram Five Fingers product (I hesitate to call it a shoe).

When I owned the running store mentioned in the previous post I soon discovered there wasn't one shoe selection that would work best for all runners. But gradually I came to realize that runners are less likely to have injuries and to perform better if they use the least shoe possible for them. Note that 'for them' is quite a broad qualifier. A 115-pound woman with excellent running technique and years of training injury-free can generally get by quite nicely with the least shoe possible. Whereas a 220-pound runner with flat feet and awful run technique who is in his first year of serious running will need something far more supportive on his feet.

I wish it was so easy as to say that we should all just run barefoot. Had we grown up like Kenyan kids - barefoot and running to school every day - we wouldn't need heavy-duty shoes at all. Our feet and legs would be strong and our technique would be excellent. Unfortunately, that simply isn't the case. We grow up wearing shoes as soon as the parents can dress the baby. I'm afraid the feet of most of us are not well-conditioned. But we can do something about that.

I think it might help if you got out of your shoes during the day whenever you can. I'm not talking about running shoes here, but rather your 'street' shoes. Taking them off around the house is a minimal but first step in strengthening your feet. Athletes who do this can progress to doing what I call 'barefoot strides' a couple of times a week. I start them off with doing 5-6 x 20 second sprints on a clean, grassy surface (with walk-back recoveries). If not ready for barefoot running try using a lightweight racing flat, Nike Frees, beach water shoes or Vibrams. The idea is to gradually do more walking and running with little or no footwear.

I doubt if you will ever want to do all of your training and racing barefoot, although some do. The real advantage to doing this is not necessarily to run with a minimal shoe but to strengthen your body so injury is less likely. If that eventually involves wearing a minimalist shoe that's okay. I don't happen to see that so much as a goal as a means to training injury-free and eventually racing faster.
